ABM3-25.000MHZ-B2-T,无线应用晶振,ABM3晶体,5032贴片晶振,艾博康无源晶振
| 型号名称Model name： | ABM8 | 品牌 brand ： | ABRACON |
| 原厂型号Original model ： | ABM3-25.000MHZ-B2-T | 尺寸size ： | 5032mm |
| 产品类型Product type： | 陶瓷谐振器 | 高度 Package Height： | 1.30mm |
| 频率frequency ： | 25MHz | 工作温度Operating Temperature ： | -20℃~70℃ |
| 频率公差Tolerance ： | ±20ppm | 等效串联电阻 ESR ： | 30 Ohms |
| 负载电容 Load capacitance ： | 18pF | 包装类型Packaging Type : | 5032-SMD |
| 产地Origin： | 美国 | 制造商Manufacturer ： | ABRACON |
| 安装方式Installation ： | Surface Mount | 最小包装数 MPQ ： | 1000 / reel |
ABM3-25.000MHZ-B2-T,无线应用晶振,ABM3晶体,5032贴片晶振,艾博康无源晶振
| ABM3-11.050MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 11.05MHz | ±20ppm | 18pF |
| ABM3-13.52313MHZ-10-B4Y-T | ABRACON | ABM3 | MHz Crystal | 13.52313MHz | ±30ppm | 10pF |
| ABM3-8.000MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 8MHz | ±20ppm | 18pF |
| ABM3-8.000MHZ-J4Q-T | ABRACON | ABM3晶体 | MHz Crystal | 8MHz | ±30ppm | 18pF |
| ABM3-30.000MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 30MHz | ±20ppm | 18pF |
| ABM3-9.8304MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 9.8304MHz | ±20ppm | 18pF |
| ABM3-14.7456MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 14.7456MHz | ±20ppm | 18pF |
| ABM3-24.000MHZ-B4Y-T | ABRACON | ABM3 | MHz Crystal | 24MHz | ±30ppm | 18pF |
| ABM3-25.000MHZ-D4Y-T | ABRACON | ABM3 | MHz Crystal | 25MHz | ±30ppm | 18pF |
| ABM3-40.000MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 40MHz | ±20ppm | 18pF |
| ABM3-29.4912MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 29.4912MHz | ±20ppm | 18pF |
| ABM3-18.432MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 18.432MHz | ±20ppm | 18pF |
| ABM3-22.1184MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 22.1184MHz | ±20ppm | 18pF |
| ABM3-12.000MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 12MHz | ±20ppm | 18pF |
| ABM3-16.000MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 16MHz | ±20ppm | 18pF |
| ABM3-13.560MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 13.56MHz | ±20ppm | 18pF |
| ABM3-24.000MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 24MHz | ±20ppm | 18pF |
| ABM3-28.6363MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 28.6363MHz | ±20ppm | 18pF |
| ABM3-27.000MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 27MHz | ±20ppm | 18pF |
| ABM3-18.432MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 18.432MHz | ±20ppm | 18pF |
| ABM3-48.000MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 48MHz | ±20ppm | 18pF |
| ABM3-12.000MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 12MHz | ±20ppm | 18pF |
| ABM3-12.288MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 12.288MHz | ±20ppm | 18pF |
| ABM3-10.000MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 10MHz | ±20ppm | 18pF |
| ABM3-25.000MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 25MHz | ±20ppm | 18pF |
| ABM3-20.000MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 20MHz | ±20ppm | 18pF |
| ABM3-24.000MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 24MHz | ±20ppm | 18pF |
| ABM3-16.000MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 16MHz | ±20ppm | 18pF |
| ABM3-11.0592MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 11.0592MHz | ±20ppm | 18pF |
| ABM3-8.000MHZ-B4Y-T | ABRACON | ABM3 | MHz Crystal | 8MHz | ±30ppm | 18pF |
| ABM3-20.000MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 20MHz | ±20ppm | 18pF |
| ABM3-30.000MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 30MHz | ±20ppm | 18pF |
| ABM3-27.000MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 27MHz | ±20ppm | 18pF |
| ABM3-32.000MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 32MHz | ±20ppm | 18pF |
| ABM3-24.576MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 24.576MHz | ±20ppm | 18pF |
| ABM3-16.384MHZ-B4Y-T | ABRACON | ABM3 | 进口无源晶振 | 16.384MHz | ±30ppm | 18pF |
| ABM3-33.000MHZ-B2-T | ABRACON | ABM3 | MHz Crystal | 33MHz | ±20ppm | 18pF |
| ABM3-26.973MHZ-12-B2-T | ABRACON | ABM3 | MHz Crystal | 26.973MHz | ±20ppm | 12pF |
| ABM3-12.000MHZ-B2H-T | ABRACON | ABM3 | MHz Crystal | 12MHz | ±20ppm | 18pF |
| ABM3-19.6608MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 19.6608MHz | ±20ppm | 18pF |
| ABM3-33.000MHZ-D2Y-T | ABRACON | ABM3 | MHz Crystal | 33MHz | ±20ppm | 18pF |
